4224 710 9502 STIHL Adjusting Screw – Genuine OEM Part
The STIHL Adjusting Screw (4224 710 9502) is a genuine OEM replacement adjusting screw designed for use with the support and guard assembly with water attachment on select STIHL cut-off saws, including the TS 700 and TS 800.
This adjusting screw is used to fine-tune and securely position components within the guard support and water attachment assembly. Proper adjustment is essential for correct alignment, stable operation, and effective dust suppression during cutting applications.
Manufactured to STIHL factory specifications, this OEM adjusting screw ensures precise threading, correct length, and reliable holding strength in demanding jobsite environments. Replacing worn, stripped, or missing adjusting screws helps maintain proper guard positioning and safe operation.
⚠️ Note: Water tank not included. Sold separately.
Product Details
-
OEM Part Number: 4224 710 9502
-
Brand: STIHL (Genuine OEM)
-
Part Type: Adjusting Screw
-
Application: Support with guard with water attachment
-
Condition: New Genuine OEM Part
Replaces Old Part Number: 4224 710 9501
Function
This OEM adjusting screw is designed to:
-
Adjust and secure guard support components
-
Maintain proper alignment of the water attachment system
-
Replace stripped, worn, or missing adjusting screws
-
Support stable operation and safe cutting performance
⚠️ Improper adjustment or damaged screws may cause loose guards, poor water delivery alignment, or unsafe operating conditions.
Verify Fitment (Recommended)
Before ordering, confirm:
-
OEM part number 4224 710 9502
-
Application matches your saw’s guard and water attachment configuration
-
Fitment corresponds to your STIHL illustrated parts diagram
⚠️ Guard and water attachment components may vary by production version — always verify by OEM part number.
Compatibility
This OEM adjusting screw fits select STIHL cut-off saw models equipped with guard support and water attachment assemblies, including:
-
TS 700 (Support with guard with water attachment)
-
TS 800 (Support with guard with water attachment)
(Exact application depends on configuration — verify using OEM parts diagram.)
Installation Notes
-
Remove the guard or support assembly as required
-
Remove the old adjusting screw carefully
-
Install the new OEM adjusting screw in the correct position
-
Adjust according to STIHL specifications for proper alignment
-
Confirm secure mounting before operation
⚠️ Do not over-tighten. Professional installation is recommended.
Maintenance Tips
-
Inspect adjusting screws regularly for tightness
-
Replace stripped or corroded fasteners immediately
-
Keep water attachment components clean and debris-free
-
Use only genuine STIHL OEM fasteners for correct fit and durability
