06200510 – Ariens / Gravely Hex Bolt 1/2″-13 × 9.00″ Grade 5 Zinc-Coated (Genuine OEM)
Description:
The 06200510 hex bolt is a genuine OEM Ariens / Gravely fastener engineered for front caster wheel assemblies on a wide range of commercial zero-turn and electric mower platforms. This 1/2″-13 × 9.00″ Grade 5 bolt provides the strength and length required for secure caster mounting while allowing proper wheel articulation and alignment.
Manufactured from Grade 5 hardened steel and finished with a zinc coating (ZCC), this bolt delivers excellent tensile strength, corrosion resistance, and durability in high-vibration, outdoor mowing environments. It is designed to withstand continuous steering loads and impacts encountered by front caster assemblies.
Built to Ariens and Gravely factory specifications, the 06200510 bolt ensures proper fitment, correct clamping force, and long service life. It installs as a direct OEM replacement with no modification required.
Key Details
-
Manufacturer Part Number: 06200510
-
Part Type: Hex Head Bolt
-
Thread Size: 1/2″-13
-
Length: 9.00″
-
Grade: 5
-
Finish: Zinc-Coated (ZCC)
-
Brand: Ariens / Gravely
-
Application: Front caster wheel mounting
-
Installation: Direct OEM replacement
Compatibility
The Ariens / Gravely 06200510 bolt is used extensively in front caster wheel assemblies on the following equipment platforms:
Gravely Commercial Zero-Turn Models
-
Zenith 52" SD CE
-
Zenith 52" RD CE
-
Zenith 60" SD CE
-
Zenith 60" RD CE
-
Apex 48 SD CE / RD CE
-
Apex 52 SD CE / RD CE
-
Apex 60 Limited
Electric Zero-Turn Models
-
Zenith E 48 CE (SD & RD)
-
Zenith E 52 CE (SD & RD)
-
Zenith E 60 CE (SD & RD)
Used across multiple serial number ranges and production updates for caster wheel and wheel hub assemblies.
Why Use Genuine OEM 06200510
-
Correct length and thread pitch for caster assemblies
-
Grade 5 strength for steering and impact loads
-
Zinc coating resists rust and corrosion
-
Maintains proper caster alignment and wheel tracking
-
Ensures factory-correct fit and long-term reliability
The OEM Ariens / Gravely 06200510 bolt is the correct replacement choice for maintaining safe, smooth, and durable front caster wheel operation on compatible Zenith and Apex commercial mowers.
